Description

XPS 16K is a four-channel power amplifier with advanced processing and analog/digital routing options for both touring and install use. With 4×4000 W Class D continuous power at 2.7 ohms, 40-bit floating-point processing at 96 kHz, and 32-bit internal routing, XPS 16K packs extreme power density in a 2U chassis. Designed for both touring and installed sound systems, XPS is intended for use with high-performance speakers and provides ready-to-use configurations and presets. It can also be used in linear mode with advanced tuning capabilities. Each output features: 4000 ms output delay (1372 m / 4501 ft), EQ Filters, Crossovers, FIR Filters, Multiband Compressor, RMS Limiter, and Thermal limiter. XPS delivers rider-friendly premium sound with full RDNet remote management, large touch interface onboard, exceptional signal/noise ratio, ultra-low distortion, and extreme dynamic range.

• 16000 W Total Continuous Power
• 40-bit Floating-point Processing, up to 96 kHz
• 32-bit Fixed-point Internal Routing
• FiRPHASE, Bass Motion Control, Bass Shaper
• RDNet Networked Management
• Touch 4.3″ Color TFT Interface
• Full On-board Processing with Delay, EQ, Comp/Limiter
• On-board Speaker Presets Library

Outstanding. Power. Processing.

4 x 4000 W

Class D continuous power at 2.7 Ohms

40-bit Floating-point

Processing at 96 kHz

Ready-to-Use

Configurations and presets for RCF speakers

2U Rack Space

for both touring and installed sound systems

Flexible 32-bit Routing

with analog, digital and Dante I/O

Advanced Fault Protections

for each amplifier channel and power supply

Installed Audio

Quality Power for Fixed Sound Systems

XPS Series is the best choice for high-power installation systems such as auditoriums, theme parks, and performance venues. Whether perfectly integrating with RCF passive speakers with ready-to-use presets, XPS provides installation-specific features, including enhanced system status monitoring, GPIOs for extended capabilities, flexible routing, and perfect integration with our proprietary RDNet management platform.

Tour Sound

Thinking Out of the Box, and Into The Rack

XPS shines when used in touring applications and live events from medium to very large capacity. Paired with RCF high-powered passive speakers, XPS gives a new perspective in sound system management. The system designer now has complete flexibility in choosing powered, or externally amplified speakers, balancing portability, weight, ease of installation, cabling, fast setup speed, and complete remote management, via RDNet.

Power to Change Everything

Four-Channel Modular Amplifier

XPS 16K provides extreme power density with 4 x 4000 W continuous power outputs in 2 RU space for both touring and installed sound systems. The unit features 4 analog and digital AES/EBU inputs/outputs, a Dante Network ready design, and complete signal processing, tuning, and routing capability all at 96 kHz. Redundancy and full scalability are granted by the advanced and modular design of the circuitry. A complete set of RCF speaker presets is available, with powerful signal processing for complete system tuning.

New Attitude in Sound Management

XPS 16K supports the RCF philosophy with a power-agnostic approach, where the sound system engineer has complete freedom in choosing powered, or externally amplified, modules for their system. XPS 16K offers a new solution for balancing portability, weight, ease of installation, cabling, fast setup speed, and complete remote management of each connected device, via RDNet.

Power You Can Trust

RCF’s effort in assisting both installers and sound providers with the best audio technology and clear, powerful sound is at the core of the company’s beliefs. Since 1949, providing both power amplifiers and transducers to the professional market, the RCF experience marks a new milestone with XPS 16K.

XPS Series

High-Density Power Amp Solutions designed for high-performance speakers with advanced Processing and flexible Routing.

READ MORE

Specifications

Amplifier Class

D

Output Power (Eiaj 8:32 All Channels Driven)

4 X 4000 W @ 2.7 Ohm
4 X 2600 W @ 4 Ohm
4 X 1400 W @ 8 Ohm

Frequency Response (-3db)

20 Hz ÷ 23000 Hz

Snr Analog Inputs (Unweighted)

>111 Db

Snr Digital Inputs (Unweighted)

>115 Db

Crosstalk

<70 Db

Distortion (Thd+N) (20 Hz ÷ 20000 Hz,1000 W @ 4 Ohm)

<0.2 %

Gain (Linear Mode @ 0 Db)

32 Db

Damping Factor (@ 4 Ohm, 20 Hz ÷ 1500 Hz)

>95

Max Burst Length (@ 50 Hz, Cf = 7 Db, 4 Ohm, 1% Thd+N)

200 Ms

Input Section

Total Number Of Inputs

8

Line Inputs

4

Line Connectors

Xlr

Digital Inputs

4

Digital Connectors

Xlr

Digital Type

Aes/Ebu

General Purpose Inputs (Gpi)

2

Programmable Gpi

Yes

Photo-Coupled Gpi

2

Output Section

Signal Output Number

4

Signal Output Connectors

Xlr

Power Output Connectors

Speakon

General Purpose Outputs (Gpo)

3

Programmable Gpo

Yes

Processing

Dsp

2 Sharc, 40-Bit Floating Point, 96 Khz
2 Adau, 32-Bit Fixed Point, 96 Khz

Eq Filters

Peaking | Hi/Lo-Shelving | Hi/Lo-Pass (Butterworth, Linkwitz-Riley, Bessel)

Advanced Algorithms

Firphase Technology | Bass Shaper | Air Compensation | Mid-Low Correction | Driver Excursion Control | Dynamic Peq | Multi-Band Compressor | Pilot Tone Detection | Backup Recovery Strategy | Impedance Load Measurement

Compressors

Rms Limiter | Dynamic Compressor | Power Limiter | Thermal Compressor

Delay

0 ÷ 4000 Ms (Each Channel)

Tone Controls

Yes

High-Pass Filter

10 Hz ÷ 1000 Hz

Crossover

2500 ÷ 3500 Hz

Automatic Gain Control

Yes

Configuration And Control

Configuration

Front Panel Touch Screen, Pc Software

Network

Gigabit Ethernet

Rcf Speakers Presets

Yes

Priority

Yes

Protocols For System Integration

Proprietary Osc Based Protocol, Q-Sys

Rdnet

Yes

Protections

Cooling

Forced

Short Circuit

Yes

Thermal

Yes

Dc

Yes

Fuses

Yes

Vhf (Very High Frequencies)

Yes

Operating Conditions

Temperature Range – Continuous Operation

-5°C ÷ +40°C / +23°F ÷ +104°F

Temperature Range – Reduced Output Power

-5°C To +50°C / +23°F To +122°F

Fan Noise Idle < (Dba)

<35 Dba

Fan Noise Max < (Dba)

<64 Dba

Power Requirement

Operating Voltage

90-240 V~ 50/60hz

Nominal Current Ac @ 100-120 V

30 A

Nominal Current Ac @ 220-240 V

16 A

Stand By Power Consumption

20 W

Idle Power Consumption

90 W

Power Consumption (Max)

5800 W

Main Fuse

Internal

Standard Compliance

Safety Agency

Ce Compliant, Ul 62368-1, 3rd Ed.
Csa C22.2 No. 62368-1:19, 3rd Ed.

Physical Specifications

Cabinet/Case Material

Metal

Handles

2 Metal Handles For Rack Mount

Color

Black – Ral 9005

Rack Mounting

19″, 2u

Size

Height

88.7 Mm / 3.49 Inches

Width

482 Mm / 18.98 Inches

Depth

482.4 Mm / 18.99 Inches

Weight

15 Kg / 33.07 Lbs

Shipping Information

Package Height

150 Mm / 5.91 Inches

Package Width

580 Mm / 22.83 Inches

Package Depth

600 Mm / 23.62 Inches

Package Weight

18 Kg / 39.68 Lbs
